D-Type Ni-MH Batteries

Name: D-Type Ni-MH Batteries
Brand: Shenzhen Better Power Battery Co., Ltd.
Availability: InStock

The D-type nickel-metal hydride (NiMH) battery, commonly known as No. 1 NiMH battery, has a capacity ranging from 2,600 mAh to 11,000 mAh, a height of 60.0–61.5 mm, and a diameter of 32.0–32.5 mm. It is suitable for applications such as electric windows, lighting systems, mining equipment, and more.

Get Free Quote

Specifications of D-Type Ni-MH Batteries

Model	Nominal Voltage (V)	Internal Resistance (mΩ)	Diameter (mm)	Length (mm)	Weight (g)	IEC Cycle Life (cycles)
BPI-60D10000mAh	1.2V	20mΩ	32.0~32.5	58.8~60	110	＞1000
BPI-60D7000mAh	1.2V	20mΩ	32.0~32.5	58.5~60.0	128	＞1000
BPI-60D9000mAh	1.2V	18mΩ	32.0~32.5	58.5~60.0	155	＞1000
BPI-60D10000mAh	1.2V	18mΩ	32.0~32.5	58.5~60.0	156	＞1000
BPI-60D4000mAh	1.2V	25mΩ	32.0~32.5	60.0~61.5	93	＞1000
BPI-60D41000mAh	1.2V	25mΩ	32.0~32.5	60.0~61.5	98	＞1000
BPI-60D10000mAh	1.2V	20mΩ	32.0~32.5	60.0~61.5	110	＞1000
BPI-60D6000mAh	1.2V	20mΩ	32.0~32.5	60.0~61.5	125	＞1000
BPI-60D7000mAh	1.2V	20mΩ	32.0~32.5	60.0~61.5	128	＞1000
BPI-60D8000mAh	1.2V	≤10mΩ	32.0~32.5	60.0~61.5	144	＞1000
BPI-60D9000mAh	1.2V	≤10mΩ	32.0~32.5	60.0~61.5	155	＞1000
BPI-60D10000mAh	1.2V	≤10mΩ	32.0~32.5	60.0~61.5	156	＞1000
BPI-60D11000mAh	1.2V	≤10mΩ	32.0~32.5	60.0~61.5	160	＞1000
BPI-62D2600EH mAh	1.2V	25mΩ	32.0~32.5	60.0~61.5	90	＞1000
BPI-62D3000EH mAh	1.2V	25mΩ	32.0~32.5	60.0~61.5	90	＞1000
BPI-62D9500EH mAh	1.2V	≤10mΩ	32.0~32.5	60.0~61.5	162	＞1000

Key Characteristics of D-Type Ni-MH Batteries

High Capacity

Reliable High Capacity

Low Short-circuit Risk

Low Internal Resistance

Efficient and Stable Energy Output

Long-Lasting And Stable Power Support

Low Short-circuit Risk

Low Internal Resistance

High Current Discharge Capability

Meets High Power Requirements

Temperature Monitoring

Real-Time Temperature Monitoring

Features of D-Type Ni-MH Batteries

Applications of D-Type Ni-MH Batteries

The D-type Ni-MH battery delivers exceptional performance with a high capacity of 11,000 mAh, providing sustained power for high-demand devices such as searchlights, power tools, and outdoor audio systems. It reduces replacement frequency, offers excellent cycle life, and lowers long-term costs. Customization options (e.g., size, capacity, protection circuits, cable length) are available to meet specific client needs. Our R&D team collaborates closely with customers to deliver optimal power solutions.

Additional features include:

High capacity
Low self-discharge
No memory effect
Extended cycle life
Rapid charging capability
Stable voltage output
Superior safety performance
Low short-circuit risk
Wide operating temperature range
Compatibility with multiple devices
Eco-friendly and pollution-free
Multiple certifications (UL/CE/Battery Directive Certification IEC 62133)

Widely used in camp lighting, GPS trackers, electric sprayers, large remote-controlled toys, portable testing instruments, mining equipment, and other fields.
